ME700/700 LED Surgical Light Operating Room Light Ceiling-mounted
Germany LED Light sources
Me700/700 LED Surgical lamp feature:
1. 700/700 series LED operating light meets all kinds of operation,
it using unique light gathering technology,with deep focus depth,
microcomputer digital control and adjustable brightness and light
spot.
2. Medeco LED light could based on different countres customer
adjust the power and votage To ensure that customers can use it
safely and securely in the local area.
3. Medeco LEd light support OEM, print the customer logo in our
front of products and nameplate,Fully show the image of the
customer.
4. Germany Square Arm support unlimited rotating(Optional)
5. HD Medical Camera System(Optional)
6. Remote control and touch-screen Optional
7. Support: Wall Type, Mobile Type, Mobile with battery, Single
dome, Double dome.
Configuration for Me700/700 LED Surgical Lamp:
1. Round Bottom Falun Plate Light Base
2. The lamp balance arm standard using Chinese Domestic Round arm(Germany Ondal Square Arm Optional)
3. Two pcs sterilizer handling for one lamp head
Option: Germany Square Arm, Chinese Square Arm.
3. German Orsam bulb and lamp-socket
4. As a flexible lighting solution, halogen light can be easily
changed when another burned.
5. Double control
6. HD Camera System
7. One Led Operation light head and one Chinese Round Arm.
Specification for Me700/700 LED Surgical Lamp
| Technical specifications for lights | LED700 OT lamp | LED700 OT Lamp |
| Illumination(Lux) | 40,000~160,000 (8 levels) | 40,000~160,000 (8 levels) |
| Focusable light-field size (mm) | 150~300 | 150~300 |
| Colour temperature | 3500 4000 4500 5000 | 3500 4000 4500 5000 |
| Light Depth L1+L2(mm) | >1000 | >1000 |
| Colour Index Ra | >95 | >95 |
| Power Supply | 110~240V 50/60Hz | 110~240V 50/60Hz |
| Effective bulb service life | >50,000h | >50,000h |
| Diameter of lamp housing | 650mm | 650mm |
| Power (W) | 80 | 80 |
| Installation height (Ceiling Type) | 280-320 cm | 280-320 cm |
| Endoscopy model | Available | Available |
